Injection Molding of PP Sink Covers
One of our clients in the Changchun Green Park has been using Supermaster 1050 TP-SVP/2 plastic injection mold machines in their production line since 2015. Using the mold’s duel 1 + 1 cavities, they are simultaneously producing left and right sink covers in a single cycle. The covers are 820x380x65 mm, and 800x350x65 mm with a wall thickness of 2 mm.
This manufacturer presently has 23 machines in operation. Each machine uses an Ai 12 controller, operates in semi-automatic mode and is set to a clamping capacity of 1050 tons. The covers being produced on these machines are made with 318 + 270 gram shots of PP, with a 63 second cycle time.
The flexibility of this two-platen machine makes it the perfect machine for production of larger components with high quality requirements and a high yield rate.
Machine Details
- Model:
SM1050-TP-SVP/2 Type: Two-Platen
Year: 2015
Clamping Force: 1050 tons
Power Pack: SVP/2+ Servo Drive
Controller: Ai 12
Operator Details
Country: China
Location: Changchun
Number of Machines: 23
Part Details
Part: Sink Covers
Resin: PP
Cavities: 2
Dimensions: 820mm X 320mm X 65mm & 800mm X 320mm X 65mm
Product weight: 318 grams + 270 grams
Thickness: 2mm
Cycle Time: 63 seconds
Op Mode: Semi-automatic
